Exhibition time

Exhibition time

October 16-18

October 16-17 09:00-16:30

October 18, 09:00-14:00

Exhibition location

venue

Beijing China International Exhibition Center (Shunyi Hall)

Booth number: E1-B20

Company Profile

Company Profile

Qingdao Laser Test Innovation Technology Co., Ltd. (referred to as Laser Test Innovation) was jointly established by an expert team from the Ocean University of China and the Anguang Institute of the Chinese Academy of Sciences. It has been recognized as a national high-tech enterprise and a national-level specialized and special "little giant" enterprise. , Shandong Province Specialized and New Enterprises, Shandong Province Gazelle Enterprises, Shandong Province Provincial New R&D Institutions, etc.

The company focuses on core needs such as smart wind power, environmental meteorological three-dimensional monitoring, aviation safety and efficiency improvement, and focuses on the research and development, manufacturing and technical services of environmental meteorological, atmospheric and ocean detection lidar. The relevant equipment achievements won the second prize of the Ministry of Education Science and Technology Progress Award. , second prize of Qingdao Science and Technology Award.

Exhibited products

Exhibition Product

Product 1: Vertical wind tower type wind lidar

WindMast WP350 is a "wind tower replacement" pulse coherent wind lidar, designed and manufactured entirely based on the requirements of the IEC 61400-12-1 standard. Miniaturized, low power consumption, high precision, it can continuously detect wind speed and direction profiles at any 24 height doors from the ground to 350m all day long.

Product Highlights

It has been certified by international authorities such as DNV and WindGuard, and its technology has reached the international advanced level.

Application scenarios include wind resource survey and assessment, wind turbine power curve testing, wind power prediction, complex terrain wind shear analysis, atmospheric boundary layer dynamics research and other fields.

The radar has excellent environmental adaptability and can work stably and reliably in harsh conditions such as deserts, plateaus and even oceans.

The products are exported to Europe, America, Southeast Asia, Central Asia and other markets, and have received unanimous praise from customers at home and abroad.

Product 2: Floating wind lidar system

The floating wind lidar system is a maritime mission platform designed and produced to meet the needs of mobile wind measurement at sea. It can be equipped with a variety of meteorological and hydrological sensors to detect wind, waves, currents, pressure, illumination, rainfall and other multi-dimensional aspects in the target sea area. , multi-level data.

Product Highlights

The first domestically produced floating wind lidar product that has passed OWA Stage2 certification.

Application scenarios include offshore wind resource survey and assessment, wind turbine power curve testing, wind power prediction, air-sea boundary layer dynamics research, offshore meteorological data collection, ocean current monitoring and other fields.

Nearly a hundred sets of floating systems and offshore platform equipment have been deployed in China's coastal areas. They have perfectly passed the test of multiple strong and super typhoons such as "Dusuri", "Gemei" and "Capricorn", and have extremely strong maritime survivability. ability.

Product 3: Three-dimensional scanning wind lidar

The three-dimensional scanning wind lidar Wind3D 6000/10K can achieve refined detection of the three-dimensional wind field in the atmospheric boundary layer. It is equipped with a high-pointing precision optical scanning mirror to realize the 3D scanning detection function - fixed point/DBS/VAD/PPI/RHI/ CAPPI script programming scan mode.

Product Highlights

Application scenarios include complex terrain wind resource survey and assessment, wind turbine power curve testing, wind power prediction, offshore wind resource survey, wind turbine wake research, wind farm optimization control and other fields.

In response to complex wind power wind measurement needs such as refined wind measurement on complex terrain, research on wind turbine wake detection, and offshore remote virtual wind measurement towers, we have independently developed multiple detection modes such as radar three-dimensional slice scanning, virtual wind measurement tower, and multi-radar collaboration. Inversion algorithms and customized business software.

The radar has excellent environmental adaptability and can work stably and reliably in harsh conditions such as deserts, plateaus and even oceans.

Product 4: Cabin-type wind measuring lidar

WindHorizon H400 (H800) cabin-type wind measurement lidar can achieve precise detection of wind speed and direction at any 10 (20) range gates 50m to 400m (800m) directly in front of the wheel hub. The lidar is small in size, light in weight and has low power consumption. , which can be easily installed and transported on the top of the fan.

Product Highlights

It has been certified by DNV international authority and its technology has reached the international advanced level.

Application scenarios include wind turbine yaw error correction, wind turbine power curve testing and feedforward control to reduce wind turbine load. It is compatible with communication protocols such as CANopen and Modbus.

It independently develops algorithms for yaw correction, wind speed and wind power prediction, and deeply participates in the IEA Wind TCP international cooperation project, always maintaining technological leadership.

The radar has excellent environmental adaptability and can work stably and reliably in harsh conditions such as mountains, plateaus and even oceans.

Product 5: Laser Clearance Radar

Laser clearance radar uses the principle of laser ranging to build a blade clearance monitoring system, which is used to monitor the clearance distance between the blades and the tower in real time under the operating conditions of the wind turbine. When the blade clearance value is less than the standard value, an alarm is triggered through the blade clearance monitoring system. The main control of the wind turbine unit can take protective measures to ensure the safe operation of the wind turbine and thereby increase power generation.

Product Highlights

It has excellent environmental adaptability and can work stably and reliably in harsh conditions such as mountains, plateaus, and oceans.

Compatible with CANopen, Modbus and other communication protocols.

The adaptive threshold can realize intelligent discrimination of target echoes under the interference of clouds, fog, rain and sea surface sunlight.

Traffic guidance

subway

National Exhibition Center Station of Metro Line 15

Self drive

Navigate to "China International Exhibition Center (Shunyi Hall)"

(No. 88, Tianzhu Yuxiang Road, Shunyi District, Beijing)

PARKING LOT

Parking is available at P2A and P3A of the exhibition hall.
